DYNAMICS - EXAMPLE
Collision of Two Balls		Example
		Two balls, A and B, impact each other as shown. If the coefficient of restitution, e, is 1.0 (perfectly elastic), what is the velocity magnitude of ball B after impact?

		Solution
Velocity of Balls Before and After Collision		Ball B only has a velocity in the y-direction, so first consider y-direction momentum. Conservation of momentum before and after impact gives m_Av_A1y + m_Bv_B1y = m_Av_A2y + m_Bv_B2y 4 cos30 - 3 = -v_A2y + v_B2y 0.4641 = -v_A2y + v_B2y There are still unknowns, so the impact equation needs to be used, e = (v_B2y - v_A2y)/(v_A1y - v_B1y) 1 = [v_B2y - (-v_A2y)] / [4 cos30 - (-3)] 3.464 + 3 = v_B2y + v_A2y 6.464 = v_B2y + v_A2y Combining both equations 0.4641 = -(6.464 - v_B2y) + v_B2y 0.4641 + 6.464 = 2v_B2y v_B2y = 3.464 m/s v_B2y = v_B2 = 3.464 m/s
