 Rotating Spring Arm |
Example |
|
| A 5 kg collar slides along a rod that is rotating. The collar is also attached to the center with a spring. There is friction between the collar and the bar, μ = 0.3. At a particular time, dθ/dt = 1.2 rad/s, dr/dt = 0.9 m/s, d2r/dt2 = 1.3 m/s2, and r = 0.7 m. The angular velocity is constant. What is the force magnitude acting on the collar due to the spring? Neglect gravity. | ||
| Solution |
||
|
|
The acceleration in the radial and theta directions need to be determined before summing forces. The given information is, Substituting into acceleration equations, Summing forces and accelerations give, ΣF = mar |
|
