DYNAMICS - EXAMPLE
    Example

Car Acceleration

The acceleration of a car over time is know as a(t) = (2t2 + t) m/s2. Assuming the car starts from rest, how far does the car travel in 5 seconds?

    Solution


Car at t = 0 and t = 5 seconds.



Since distance is needed, the acceleration equation must be integrated twice. First, find the velocity function,



Notice, the integration was done with time, t, and not 5 seconds. Since the velocity at 5 seconds is not requested, only the general velocity function is determined.

Next, find the distance traveled in 5 seconds by integrating the velocity function that was just determined,



The final position after 5 seconds is

x = (625 + 125) / 6 = 125 m


Example Problem 1



Example Problem 2



Example Problem 3



Example Problem 4



Example Problem 5



Example Problem 6



Example Problem 7



Example Problem 8



Example Problem 9



Example Problem 10



Example Problem 11



Example Problem 12



Example Problem 13



Example Problem 14



Example Problem 15



Example Problem 16



Example Problem 17
